Description

- special durable device for commercial usage in heavy industries
- GPS/GLONASS, remote configuration
- shake sensor, 3D accelerometer
- active antenna, temperature sensor
- energy efficiency, endurance, battery life for up to 10 years
- easy to install, resistance (IP67)
- low maintenance cost
- new technology with the prospect for development
- low operating fee data transfers
- no roaming, devices work where there is coverage by SIGFOX

Use cases

- logistics and containers tracking
- asset managementt
- rolling stocks
- heavy industries
- demanding environment
- theft prevention
- fleet management
- vehicles rental
- waste management
- quality measurement

Technical Specification

Size160mm x 80mm x 55mm
Weight410g*
Battery typeLi-SOCl2, 17 000 mAh, type D, replaceable
Autonomy6 to 10 years
Geo - localisationshigh precision GNSS receiver
Emissions class: Sigfox ready U0, RCZ1, CFU 868.13MHz/CFD 869.525MHz
ProtectionIP66/IP67, IK07/IK08 box, NEMA 1, 4, 4X, 12, 13
Enclosurepolycarbonate IP67
Operating temperature-30°C to +80°C
Storing temperature-40°C to +80°C
Data transmissionSigfox 25 mW/14 dBm, 162 dBm, 144 msg per day
GNSSGPS/GLONASS - TTFF <15 s @ -130 dBm, <5s @ - 130 dBm, 1 s @ - 130 dBm
GNSS technologySBAS (WAAS, EGNOS, MSAS, GAGAN), AIC, LOCUS, EASY, QZSS, AGPS
GNSS protocolNMEA – RMC, VTG, CGA, GSA, GSV a GLL
Shock sensoromnidirectional
3D accelerometer±2g, ±4g, ±8g measurement range
Antennabuilt-in GNSS and UNB Sigfox
Installationintegrated NdFeB magnets or double coated tape
*magnets are not involved
